Industrial Grade High Thermal Conductivity Expanded Flexible Sealing Graphite Paper
Product Details:
| Place of Origin: | China |
Payment & Shipping Terms:
| Delivery Time: | Peak Season Lead Time: 6-12 months, Off Season Lead Time: 1-3 months |
|---|---|
| Payment Terms: | LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram |
|
Detail Information |
|||
| Model NO.: | GP-01 | Carbon Content: | High-Carbon |
|---|---|---|---|
| Grade: | Industrial Grade | Forming Way: | Molded Graphite |
| Crystal Morphology: | Flake Graphite | Composition: | 99% Carbon |
| Transport Package: | By Carton Box | Specification: | 0.05-5mm For Thickness |
| Trademark: | DC | Origin: | China |
| HS Code: | 2701110090 | Supply Ability: | 2000 Square Meters |
| Customization: | Available | Type: | Graphite Sheets |
| Electric Conductive: | High | ||
Product Description
High Thermal Conductivity Expanded Flexible Sealing Graphite Paper:
The Description of graphite paper:
The graphite paper we produced can be widely used in the electric power petroleum, instrument, machinery, etc. It is the basic material to make all kinds of graphite composite boards, graphite strip, padding, and the sealing gasket.
Flexible graphite paper:
Flexible graphite paper is compressed by natural flake graphite, the density is 1.0-1.3g/cm3, the thickness is 0.3-1.5mm. it can not be cruled if the thickness is over 1.2. we also named it as graphite composite board in this condition.
Specification:
Our company is the professional manufacturer and exporter for carbon and graphite products. our company was established at 2000.Our factory is located in Beijing city.and 50 kilometers from Beijing airport.
We mainly produse graphite rod, graphite block, graphi.te crucible,graphite mould, graphite bearing,graphite felt,carbon fiber cloth,etc.
make it according to drawing and specifications.
for the graphite,We have mold graphite,isostatic graphite,extruded graphite,vibration graphite. bulk density from 1.6g/cm3 to 1.91g/cm3.
Carbon-graphite products for electron and semiconductor industry
Carbon-graphite products for application of processing by industrial furnace under high temperature;--
Carbon-graphite products for sintering mold of diamond tools
Carbon-graphite products for non-ferrous metallurgy and processing;
Carbon-graphite products for mechanical industry;
Carbon-graphite products for high-tech field
Carbon-graphite products for EDM
Carbon-graphite products for aviation and aerospace industry
We believe that duo to our high quality graphite material and formed graphite parts at very competitive prices with professional service,broad product knowledge and technical expertise can help you save much resource and improve your efficiency,and satisfy more of your customers' needs.
The Description of graphite paper:
The graphite paper we produced can be widely used in the electric power petroleum, instrument, machinery, etc. It is the basic material to make all kinds of graphite composite boards, graphite strip, padding, and the sealing gasket.
Flexible graphite paper:
Flexible graphite paper is compressed by natural flake graphite, the density is 1.0-1.3g/cm3, the thickness is 0.3-1.5mm. it can not be cruled if the thickness is over 1.2. we also named it as graphite composite board in this condition.
Specification:
| Thickness | Density | Sulphur | Carbon | Chlorine | Tensile Strength | |
| mm | g/cm3 | ppm | % | ppm | MPA | |
| 0.13 | 0.7-1.5 | 800-500 | 99.3 | 40 | ≥4.0 | |
| 500-200 | 99.4 | 30 | ≥4.5 | |||
| ≤200 | 99.5 | 20 | ≥5.0 | |||
| 0.2-0.5 | 0.7-1.1 | 800-500 | 99.3 | 40 | ≥4.0 | |
| 500-200 | 99.4 | 30 | ≥4.5 | |||
| ≤200 | 99.5 | 20 | ≥5.0 | |||
| 0.5-1.0 | 0.7-1.1 | 800-500 | 99.3 | 40 | ≥4.0 | |
| 500-200 | 99.4 | 30 | ≥4.5 | |||
| ≤200 | 99.5 | 20 | ≥5.0 | |||
Our company is the professional manufacturer and exporter for carbon and graphite products. our company was established at 2000.Our factory is located in Beijing city.and 50 kilometers from Beijing airport.
We mainly produse graphite rod, graphite block, graphi.te crucible,graphite mould, graphite bearing,graphite felt,carbon fiber cloth,etc.
make it according to drawing and specifications.
for the graphite,We have mold graphite,isostatic graphite,extruded graphite,vibration graphite. bulk density from 1.6g/cm3 to 1.91g/cm3.
Carbon-graphite products for electron and semiconductor industry
Carbon-graphite products for application of processing by industrial furnace under high temperature;--
Carbon-graphite products for sintering mold of diamond tools
Carbon-graphite products for non-ferrous metallurgy and processing;
Carbon-graphite products for mechanical industry;
Carbon-graphite products for high-tech field
Carbon-graphite products for EDM
Carbon-graphite products for aviation and aerospace industry
We believe that duo to our high quality graphite material and formed graphite parts at very competitive prices with professional service,broad product knowledge and technical expertise can help you save much resource and improve your efficiency,and satisfy more of your customers' needs.
