Customization 1.60/1.68/1.70/1.75g Graphite Rod for Industrial Grade
Product Details:
| Place of Origin: | China |
Payment & Shipping Terms:
| Delivery Time: | Peak Season Lead Time: 6-12 months, Off Season Lead Time: 1-3 months |
|---|---|
| Payment Terms: | LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram |
|
Detail Information |
|||
| Model NO.: | GR-175 | Grade: | Industrial Grade |
|---|---|---|---|
| Forming Way: | Extruded Graphite | Crystal Morphology: | Flake Graphite |
| Composition: | 100% Carbon | Transport Package: | By Ply-Wood |
| Specification: | Customized | Trademark: | DC |
| Origin: | Beijing, China | HS Code: | 3801100090 |
| Supply Ability: | 100PCS Per Day | Customization: | Available |
| Bulk Density: | 1.72g | Type: | Graphite Rod |
Product Description
1.60/1.68/1.70/1.75g graphite rod for hot sale:
Applications
Molds, chutes, sleeves, sheathes, linings, etc. in continuous casting systems for making shaped steel, cast iron, copper, aluminum.
Sintering molds for cemented carbides and diamond tools.
Sintering molds for electronic components.
Electrodes for EDM.
Heaters, heat shields, crucibles, boats in some industrial furnaces
(such as furnaces for pulling monocrystalline silicon or optical fibers).
Bearings and seals in pumps, turbines and motors.
and so on.
Typical Sizes
* Other dimensions are available on request.
Specifications
Our company is the professional manufacturer and exporter for carbon and graphite products. our company was established at 2000.Our factory is located in Beijing city.and 50 kilometers from Beijing airport.
We mainly produse graphite rod, graphite block, graphi.te crucible,graphite mould, graphite bearing,graphite felt,carbon fiber cloth,etc.
make it according to drawing and specifications.
for the graphite,We have mold graphite,isostatic graphite,extruded graphite,vibration graphite. bulk density from 1.6g/cm3 to 1.91g/cm3.
Carbon-graphite products for electron and semiconductor industry
Carbon-graphite products for application of processing by industrial furnace under high temperature;--
Carbon-graphite products for sintering mold of diamond tools
Carbon-graphite products for non-ferrous metallurgy and processing;
Carbon-graphite products for mechanical industry;
Carbon-graphite products for high-tech field
Carbon-graphite products for EDM
Carbon-graphite products for aviation and aerospace industry
We believe that duo to our high quality graphite material and formed graphite parts at very competitive prices with professional service,broad product knowledge and technical expertise can help you save much resource and improve your efficiency,and satisfy more of your customers' needs.
Applications
Molds, chutes, sleeves, sheathes, linings, etc. in continuous casting systems for making shaped steel, cast iron, copper, aluminum.
Sintering molds for cemented carbides and diamond tools.
Sintering molds for electronic components.
Electrodes for EDM.
Heaters, heat shields, crucibles, boats in some industrial furnaces
(such as furnaces for pulling monocrystalline silicon or optical fibers).
Bearings and seals in pumps, turbines and motors.
and so on.
Typical Sizes
| Blocks | Length x Width x Thickness (mm) 200x200x70, 250x130x100, 300x150x100, 280x140x110, 400x120x120, 300x200x120, 780x210x120, 330x260x120, 650x200x135, 650x210x135, 380x290x140, 500x150x150, 350x300x150, 670x300x150, 400x170x160, 550x260x160, 490x300x180, 600x400x200, 400x400x400 |
| Rounds | Diameter (mm): 60, 100, 125, 135, 150, 200, 250, 300, 330, 400, 455 Thickness (mm): 100, 135, 180, 220, 250, 300, 450 |
Specifications
| Specifications | Unit | Value |
| Bulk Density | g/cc | 1.70 - 1.85 |
| Compressive Strength | MPa | 25 - 70 |
| Bending Strength | MPa | 15 - 40 |
| Shore hardness | 30 - 50 | |
| Specific Resistance | micro ohm.m | 8.0 - 15.0 |
| Ash (Normal Grade) | % | 0.05 - 0.2 |
| Ash (purified) | ppm | 30 - 50 |
| Maximum Grain Size | micron | 44 |
Our company is the professional manufacturer and exporter for carbon and graphite products. our company was established at 2000.Our factory is located in Beijing city.and 50 kilometers from Beijing airport.
We mainly produse graphite rod, graphite block, graphi.te crucible,graphite mould, graphite bearing,graphite felt,carbon fiber cloth,etc.
make it according to drawing and specifications.
for the graphite,We have mold graphite,isostatic graphite,extruded graphite,vibration graphite. bulk density from 1.6g/cm3 to 1.91g/cm3.
Carbon-graphite products for electron and semiconductor industry
Carbon-graphite products for application of processing by industrial furnace under high temperature;--
Carbon-graphite products for sintering mold of diamond tools
Carbon-graphite products for non-ferrous metallurgy and processing;
Carbon-graphite products for mechanical industry;
Carbon-graphite products for high-tech field
Carbon-graphite products for EDM
Carbon-graphite products for aviation and aerospace industry
We believe that duo to our high quality graphite material and formed graphite parts at very competitive prices with professional service,broad product knowledge and technical expertise can help you save much resource and improve your efficiency,and satisfy more of your customers' needs.
